型号	流量 m3/h	转速 r/min	排出压力 MPa	必需汽蚀余量 (m)	效率 %	电动机
						频率 Hz	功率 kW	型号
YCB0.6-0.6	0.6 1.0 0.7 1.2	910 1390 1130 1710	0.6	5.5	32	50 50 60 60	0.75	Y90S-6 Y80L2-4 Y90S-6 Y80L2-4
YCB0.6-1.6	0.6 1.0 0.7 1.2	910 1400 1130 1710	1.6	7.0	70	50 50 60 60	1.1 1.5 1.1 1.1	Y90L-6 Y90L-4 Y90L-6 Y90S-4
YCB1.6-0.6	1.6 2.5 1.9 3.0	910 1400 1130 1710	0.6	5.5	42	50 50 60 60	0.75 1.1 1.1 1.5	Y90S-6 Y90S-4 Y90L-6 Y90L-4
YCB1.6-1.6	1.6 2.5 1.9 3.0	940 1440 1150 1750	1.6	7.0	71	50 50 60 60	2.2 4 2.2 4	Y112M-6 Y112M-4 Y112M-6 Y112M-4
YCB3.3-0.6	3.3 5.0 4.0 6.0	940 1420 1150 1730	0.6	5.0	60	50 50 60 60	1.5 2.2 1.5 2.2	Y100L-6 Y100L1-4 Y100L-6 Y100L1-4
YCB3.3-1.6	3.3 5.0 4.0 6.0	960 1440 1170 1750	1.6	7.0	72	50 50 60 60	5.5 7.5 4 7.5	Y132M2-6 Y132M-4 Y132M1-6 Y132M-4
YCB4-0.6	4.0 6.0 4.8 7.2	940 1420 1150 1730	0.6	5.0	60	50 50 60 60	1.5 2.2 2.2 3	Y100L-6 Y100L1-4 Y112M-6 Y100L2-4
YCB4-1.6	4.0 6.0 4.8 7.2	960 1440 1170 1750	1.6	7.0	72	50 50 60 60	5.5 7.5 5.5 7.5	Y132M2-6 Y132M-4 Y132M-6 Y132M-4
YCB8-0.6	8.0 12.0 9.6 14.4	960 1440 1170 1750	0.6	5.0	61	50 50 60 60	3 5.5 4 5.5	Y132S-6 Y132S-4 Y132M1-6 Y132S-4
YCB8-1.6	8.0 12.0 9.6 14.4	970 1460 1170 1760	1.6	7.0	75	50 50 60 60	11 15 11 15	Y160L-6 Y160L-4 Y160L-6 Y160L-4
YCB10-0.6	10.0 15.0 12.0 18.0	960 1440 1170 1750	0.6	5.0	62	50 50 60 60	4 5.5 5.5 7.5	Y132M1-6 Y132S-4 Y132M2-6 Y132M-4
YCB10-1.6	10.0 15.0 12.0 18.0	970 1470 1170 1770	1.6	7.0	76	50 50 60 60	11 15 11 18.5	Y160L-6 Y160L-4 Y160L-6 Y180M-4
YCB20-0.6	20.0 24.0	970 1170	0.6 0.6	5.0 5.0	68 68	50 60	7.5 7.5	Y160M-6 Y160M-6
YCB25-0.6	25.0 30.0	970 1170	0.6 0.6	5.5 5.5	69 69	50 60	11 11	Y160L-6 Y160L-6
YCB30-0.6	30.0 36.0	970 1170	0.6 0.6	5.5 5.5	70 70	50 60	11 11	Y160L-6 Y160L-6
YCB40-0.6	40.0 48.0	970 1180	0.6 0.6	5.5 5.5	72 72	50 60	15 15	Y180L-6 Y180L-6
YCB50-0.6	50.0 60.0	970 1180	0.6 0.6	5.5 5.5	72 72	50 60	22 22	Y200L2-6 Y200L2-6
